Rockchip RK3568 Android Embedded Board LBA3568 SBC
Keywords: arm board, single board computer, development board, embedded computer board.
- SOC: RK3568
- DDR: LPDDR4, 1GB/2GB/4GB/8GB(Optional)
- eMMC: eMMC 5.1, 8GB/16GB/32GB/64GB/128GB (Optional)
- OS: Android / Ubuntu / Buildroot / Debian
- Size: 150*100*14.2 mm
Description
Parameters
Catalog
Description
Rockchip RK3568 Android Embedded Board LBA3568 SBC for Industrial Applications
The Rockchip RK3568 Android Embedded Board LBA3568 SBC is a highly integrated industrial single-board computer (SBC) designed with the Rockchip RK3568 processor. Featuring a compact, thin, and flat structure, it is ideal for applications requiring limited structural space while delivering high performance and versatile functionality. This board provides rich hardware interfaces and is well-suited for AI computing, edge computing, and industrial automation.
Rockchip RK3568 Android Embedded Board LBA3568 SBC with Versatile USB and AI Expansion
The Rockchip RK3568 Android Embedded Board LBA3568 SBC is equipped with:
•1 x USB 3.0 HOST
•1 x USB 3.0 OTG
•2 x USB 2.0 HOST
These interfaces support the connection of multiple USB cameras, enabling applications in AI vision, surveillance, and industrial monitoring. Additionally, it features 3 mini-PCIe slots, which can be used for:
•4G module connectivity for wireless communication.
•Our mini-PCIe NPU computing card based on RK1808, providing 3.0 TOPS AI computing power when integrated with multiple cameras.
Rockchip RK3568 Android Embedded Board LBA3568 SBC with Advanced Connectivity
The Rockchip RK3568 Android Embedded Board LBA3568 SBC supports a variety of high-speed communication interfaces, including:
•Dual-band Wi-Fi
•Bluetooth 5.0
•1000M Gigabit Ethernet
•UART, I2C, and CANBUS
These features ensure seamless data transmission and robust network performance, making the board ideal for IoT, industrial control, and automation applications.
Rockchip RK3568 Android Embedded Board LBA3568 SBC with Multi-Screen Display Support
To meet the growing demand for visual applications, the Rockchip RK3568 Android Embedded Board LBA3568 SBC supports a wide range of display interfaces, including:
•2 HDMI outputs
•1 HDMI input
•Dual-channel LVDS
•Multi-screen display with independent output
These features make it an excellent choice for digital signage, AI-powered visual systems, and multi-display industrial applications.
Rockchip RK3568 Android Embedded Board LBA3568 SBC with Multi-OS Support and Open Source Code
The Rockchip RK3568 Android Embedded Board LBA3568 SBC is compatible with Android, Linux, and Ubuntu operating systems, providing a highly scalable and reliable development platform. Users can leverage open-source system code for secondary development and deep customization, tailoring the board to specific application needs.
Our company offers comprehensive technical support to assist developers and enterprises in accelerating product development, enhancing efficiency, and reducing time to market.
Parameters
Function | Description |
CPU | RK3588, quad-core Cortex-A76@2.4GHz + quad-core Cortex-A55@1.8GHz |
GPU | • Mail-G610 MP4 • OpenGL ES3.2 / OpenCL 2.2 / Vulkan1.1, 450 GFLOPS |
NPU | 6 TOPS, supports INT4/INT8/INT16/FP16 mixed operating |
VPU | Decode: 8K@60fps H.265/VP9/AVS2 8K@30fps H.264 AVC/MVC 4K@60fps AV1 1080P@60fps MPEG-2/-1/VC-1/VP8 Encode: 8K@60fps H.265/VP9/AVS2 8K@30fps H.264 AVC/MVC 4K@60fps AV1 1080P@60fps MPEG-2/-1/VC-1/VP8 |
DDR | 4GB/8GB/16GB/32GB 64bit LPDDR4/LPDDR4x/LPDDR5 |
eMMC | eMMC 5.1， 8GB/16GB/32GB/64GB/128GB(Optional) |
Network | 2×10/100/1000Mbps Ethernet Wi-Fi 2.4GHz/5GHz,802.11a/b/g/n/ac/ax, up to 433Mbps. BT 5.0 2G/3G/4G/5G(Optional) |
RAM | MicroSD(TF) with SDIO3.0 |
System | Android / Ubuntu / Buildroot |
Size | 160*115*28.25 mm |
Hardware Interface | |
Power input | 12V/2A |
USB | 4 × USB3.0 1 × USB2.0 |
Display Interface | 2×HDMI 2.1 @60fps or 4K@120fps 1×HDMI 1.4 1080P@60fps 1× LVDS 1080P@60HZ 1 × DP1.4（8K@30fps, USB 3.0） 1× DP1.2 2 Lane output 1 × HDMI-IN（4K@60fps), HDCP 2.3 Available. |
Audio Interface | 1 × 3.5mm headphone audio output 1 × 3.5mm microphone audio input 1 × HDMI audio output 2 × Speaker output (2.7W/4Ω) |
Camera Interface | 2× MIPI CSI (4 Lane) or 2×MIPI CSI (2 Lane) + 1* MIPI CSI (4 Lane) |
PCIe | mini PCIe, 2G/3G/4G available; RK1808 AI available. |
M.2 | M.2 NGFF ( M-KEY ) PCIE V2.1 x4 with NVMe SSD |
SD card | SDIO 3.0 |
Others | 5x ADC, 1x I2C(CTP available), 2*SATA，3x Uart, 1xI2C |
